Technical characteristics:
- Operation up to 5kV and 205A (depending on wire gauge #6–#1/0 AWG flat or round).
- Withstands up to 5000 psi.
- Compatible with flat or round cable.
- Gator Grip® high-conductivity electrical contact system .
- I-Seal™ technology and floating seals in each phase of the cable.
- Quick field assembly (approx. 1.5 hours) without the need for vertical splices.
- Internal insulation without filling required.
- Anti-corrosive and self-lubricating coating on the thread.
- 2-Turn Gator Loc™ Connection
- High-performance materials such as PEEK™ insulation
- Includes armor adapter for flat cable (prevents transitions).
Typical applications:
- ESP systems (electric submersible pumps) in wells with limited wellhead space.
- Field installations where rapid assembly without vertical splices is required.
- Operations in C1D1 classified environments, high pressure and temperature.
- Wells with flat or round cable, where versatility in connection is required.
- Quick replacement or maintenance of connections without dismantling the entire line.
- Wells with critical sealing and electrical insulation requirements.
